20m Bus Spray Booth Two Side Wall Extraction Gas Burner Heating Rock Wood

20m Bus Spray Booth Two Side Wall Extraction Gas Burner Heating Rock Wood

20m Bus Spray Booth Two Side Wall Extraction Gas Burner Heating Rock Wood
20m Bus Spray Booth Two Side Wall Extraction Gas Burner Heating Rock Wood
Product Details:
Place of Origin: China
Brand Name: BZB
Certification: CE,TUV
Model Number: BZB-EX3
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: USD20000-50000 Per Unit
Packaging Details: Export Pacakge or Metal Package
Delivery Time: 30-90
Payment Terms: TT or LC
Supply Ability: 2000sets Per Year
Contact Now
Detailed Product Description
Name: Industry Spray Booth Power Supply: 380V/50HZ/3Ph Or Other Option
Using Energy: Diesel,gas,steam,electric Or Other Option Main Door: Fold Style Or Electric Rolling Style
Motor: Chinese Brand Or Import Brand Control Sytem: Switch Style Or PLC Touch Screen Control
Wall: Metal Sheld,EPS,Rock Wool Of PU For Option Color: White Or Other Option
Application: Bus/truck Or Other Metallic Products Energy Sources: Water, Electricity,gas
Coating Thickness: 10-50um Dimention: As Require
High Light:

Fold Style Bus Spray Booth


Two Side Bus Spray Booth


PLC Bus Spray Booth

20m Spray Booth two side wall extraction gas burner heating


Inner size 20000×8000×5000mm(L×W×H)
Outer size 20156×11856×5800mm(L×W×H)
Main door Drive through folding door, 3 sets (one set in the middle of the room). Each size: 6000×4500mm(W×H),powder coating galvanized steel frame, 75mm rock wood wall panel, 0.476mm color plate.
Personal door 3 sets, 800×2000mm(W×H), with pressure lock and glass window.
Room body

1. Room body builds with steel frame structure, and equipped with profile steel reinforcement and built up beam.

2. 75mm rock wood panel, 0.476mm color plate, tongue and groove.

3. Room frame made by galvanized steel plate.

4. 50mm rock wood wall panel, 0.476mm color plate.

Exhaust system

1. Both side exhaust (single side cabinet divide into two parts)

2. Left, right side cabinet size: 7000×1925×1000mm(L×W×H)

Intake and Exhaust system

1. Cabinet made by power coating profile bar and coating steel. Covered by galvanized steel plate, with rock wood inside.

2. Intake with 8 sets double intake centrifugal fan. Single model: TAE-500H, power: 11KW, air capacity: 21600m3/h/each. Motor outside, belt drives.

3. Exhaust with 4 sets large impeller fan. Single model 4-82-7.1E, power 15KW, air capacity 34800m3/h/each. Motor outside, belt drive.

4. All motor CE certificate

Exhaust pipe parameter

Exhaust pipe made by high class galvanized steel plate, flange made by professional molded machine.

20 pieces exhaust straight pipe, 4 pieces straight pipe,4 pieces elbow, 4 pieces manual damper.

Heating system

4 sets of RS5 gas burner, single gas burner heating capacity: 280000Kcal/h. Max heating capacity 1120000Kcal/h. Heating exchanger made by SUS304 high class stainless steel.

Equipped with 4 sets of electric damper.

Filter system Primary filter bag, ceiling filter, fiber glass filter, active carbon filter.
Lighting system

Ceiling lighting: 36 groups*4pcs=144pcs, 36W tube.

Side lighting, 24 groups*4pcs=96pcs, 36W tube.

Philips tube, DSH-IIIB electric ballast, IL luminance ≥800LUX.

Control system Button type.( Control by two sets) Set with normal temperature spraying, constant temperature spraying, baking switch, lighting switch, temperature time setting,, emergency stop switch, failure alarm, time accumulator, temperature limited.
No load speed ≥0.3m/s Highest temperature 80℃
Voltage 380V/3P/50HZ Total power 160KW
Color White color the room body, blue color for cabinet.



Some of our Project.



20m Bus Spray Booth Two Side Wall Extraction Gas Burner Heating Rock Wood 020m Bus Spray Booth Two Side Wall Extraction Gas Burner Heating Rock Wood 1

Are you Trade company or manufacturer?
We are the manufacturer with export liscence.We have two factory in Guangzhou and  in Jiangsu,China.
How can we cooperation?
How can we cooperation?
1. Turn Key Project:
Our company will be responsible to help you to do the production line desing,manufacturing,installation,
debugging and your personnel trainging jobs,Also we will provide you one-stop service for your
production facilities procurement.
2. Equipment Supply:
Our company will not only provide you the equipments,but also will offer you the onsite installation
instruction and guidance as well.
How about after sale serivce?
1. Provide technical support and production line upgrade
2. Feedback withini 12h after receive fault notification or service requirement
3. Free training on the user’s manual
4. User-friendly English manual or operation video for machine using and maintanence.
5. One Year Gruantee.
